  • Dyana — DYA 24L70-740 NR BP 3550 CL2 L60E ANT

Dyana / DYA 24L70-740 NR BP 3550 CL2 L60E ANT

96260745

▼ Data Sheet

A high quality LED luminaire with narrow light distribution and Electronic, Programmable control gear. Equipped with 50% power reduction circuit, effective 3 hours before and 5 hours after a calculated midnight. Body, canopy and spigot: die-cast aluminium, textured anthracite finish. Enclosure: 5mm thick, toughened glass. Class Il electrical, IP66. Supplied, ready to install, in a single box. Complete with 4000K LED

Mounting: Ø60mm side entry with 0° tilt. Adjustable to -5° tilt or post-top with 5° or 10° tilt.

Dimensions: 685 x 511 x 92 mm
Luminaire input power: 51.6 W
Weight: 10.84 kg
Scx: 0.03 m²

Mode selection
  • Lamp position:STD - standard
  • Light Source:LED
  • Luminaire luminous flux*:7187 lm
  • Luminaire efficacy*:139 lm/W
  • Colour Rendering Index min.:70
  • Ballast:1 x 87500878 LCO 60/200-1050/100 NF C ADV3
  • Correlated colour temperature*:4000 Kelvin
  • Chromaticity tolerance (initial MacAdam):5
  • Rated useful life (B10)*:L90 100000 h at 25 °C
  • Luminaire input power*:51.6 W Power factor = 0.9
  • Dimming:PROG
  • LED
  • CE
  • ENEC11
  • GLedReP
  • IK10
  • IP66
  • LLedReP
  • SC2 - Protection Class 2
